Doyen Vaginal Speculum, Slightly Concave

Description

Doyen Vaginal Speculum, Slightly Concave

The Doyen vaginal speculum has one slightly concave blade for abdominal and vaginal gynecologic surgery. It comes in four blade lengths and three widths.

Four blade lengths

Fig 1 has a 55 mm blade, and Fig 2 an 85 mm blade. Then Fig 3 reaches 115 mm and Fig 4 reaches 160 mm. So the range runs from shallow vaginal work to deep abdominal exposure.

Width choices

Most figures come in 35, 45 or 60 mm widths. However, Fig 4 comes only in 45 or 60 mm. Therefore, choose a wider blade when you need to hold back more tissue.

A slightly concave blade

The gentle concave shape helps the blade cradle tissue as the assistant draws it aside. By contrast, a flat blade offers less of that cupping effect. Meanwhile, the single-blade design leaves room for other instruments.

Picking a size

Match the Doyen vaginal speculum to wound depth first, then width. For example, Fig 1 suits a shallow vaginal field, while Fig 4 suits deeper abdominal work. Plus, many trays hold two sizes to cover most cases.

Care of Doyen vaginal speculum

Rinse the concave face carefully, because residue can collect in the curve. Next, wash and brush the full length of the instrument. Afterward, dry it completely and store each size so the edges do not touch.

Doyen vaginal speculum specifications

• Blade lengths: 55, 85, 115 or 160 mm (Fig 1-4)
• Widths: 35, 45 or 60 mm
• Fig 4: 45 or 60 mm wide only
• Slightly concave single blade

Buying from Intrace USA

In addition, we cover this instrument for three years against manufacturing defects. We also inspect each order by hand in Atlanta. You can find care tips in our FAQs. Surgical stainless grades fall under ASTM F899. For a single 70×30 mm blade model, see our Doyen vaginal retractor. The rest of our OB/GYN instruments is one click away.

For trained professionals only. Notes on images and nickel content sit in our care and sterilization guide; see shipping and delivery for dispatch details.
