Millin Bladder Retractor, Replacement Blades

Description

Millin Bladder Retractor, Replacement Blades

Single blades for the Millin bladder retractor. Pick the size you need. Each listing supplies one blade, not a pair, so order two if you are replacing a matched set of laterals.

Looking for the whole instrument instead? The frame with its full blade set is the Millin Bladder Retractor, Complete.

Which size

• 57 x 25mm, lateral. The narrower of the two lateral widths. Two are fitted in a complete set.
• 80 x 25mm, lateral. The wider lateral. Two are fitted in a complete set.
• 120 x 45mm, central. The deep blade that holds the bladder back. One is fitted in a complete set.

When a blade needs replacing

Blades take the load and the knocks, which is why they wear out before the frame does. Look for a burr or a lifted edge on the working face, play in the mount, or pitting where cleaning has been rushed. Any of those is a reason to swap the blade rather than retire a frame that is otherwise sound.

Fit and care

Blades seat on the standard Millin mount and change without tools. Reprocess them off the frame, brushing the mount slot rather than rinsing it, and dry fully before refitting. Store blades flat so nothing rests on the working face.

Specification

• For the Millin retropubic prostatectomy retractor
• Sizes: 57 x 25mm lateral, 80 x 25mm lateral, 120 x 45mm central
• Supplied singly
• Material: surgical stainless steel
• Reusable, autoclavable, supplied non sterile

Warranty and supply

Each blade carries a three year warranty against manufacturing defects. Stock is inspected in the United States before it ships. See our FAQs for care guidance or browse the rest of our urology surgical instruments.

Disclaimer

Catalog images may show more than one blade size in a single photograph, so check the size you have selected before ordering. This is a professional use product. Surgical stainless steel contains nickel, and Intrace USA cannot accept liability for allergic or material sensitivity reactions. See the FDA guidance on materials used in medical devices.
